Quiz #2

Quiz #2 Quiz ID code: subnet-6177188999

The address prefix 106.158.60/22 has been assigned to the diagrammed network. Assign address prefixes to each of the subnets.

106.158.60/22

Number of HostsAddress Prefix
Token Ring A102
Token Ring B2
Token Ring C131
Token Ring D68
Token Ring E15
A-C WAN2
B-D WAN2
B-E WAN2
